Тема: замена Arduino328 на ESP32WROOM32U

здравствуйте уважаемые форумчане сайта. хочу у вас попросить помощи, кому не сложно и не жалко уделить немного времени. просьба вот какая. есть у меня вот такая игрушка сделанная мною по описанию из интернета. все работает, но построена она на Atmega328 и 74HC595. подскажите что нужно изменить в скетче что бы сменить контроллер с Atmega328 на ESP32WROOM-32U. только и всего. ни каких функций связанных с WIFI не требуется. просто что бы скетч можно было загрузить в ESP как в ардуинку и все. функционал остался тот же. я весь скетч разобрала на составные части. и поняла что принцип очень прост, но при попытке его изменить под ядро ESP32-WROOM-32U не получается самостоятельно, выдает ошибки компилятор. самой не получается, честно скажу мало знаний пока..... помогите пожалуйста. разобравшись со скетчем - поняла что в скетче SPI сконфигурирован в ручную для снижения памяти и без использования библиотеки. поэтому я так думаю что для ESP32-WROOM-32U что бы не усложнять решение вопроса, нужно все что связано SPI заменить готовой библиотекой, а остальной алгоритм адаптировать под ESP32-WROOM-32U, но не меняя функционал, но самостоятельно попробовав это сделать выдает ошибки. что бы изменить пины грамотно, для начала я посмотрела какие пины используются в ESP32-WROOM-32U для шины SPI-(MOSI/IO23-74hc595/14, SCK/IO18-74hc595/11, RCK/IO26-74hc595/12, FOTO DIODE/IO33, но как их в скетче обозначить я честно признаюсь , не знаю или PIN или GPIO или IO. все, больше ничего не требуется. индикаторный диод не обязателен.) то-есть как грамотно записать все это в скетче, не знаю. файлы все прилагаю. будьте так добры и снисходительны. помогите его изменить или подскажите как надо правильно написать. я по вашим подсказкам сама изменю под ESP32-WROOM-32U. больше из него не надо ничего делать. буду признательна если откликнитесь. или что нужно изменить, что бы правильно стал работать. буду рада если кто откликнется.

//############################################################################################################################################################
//Externe Bibliotheken einbinden//интегрировать внешние библиотеки
//############################################################################################################################################################

#include <avr/pgmspace.h>

//############################################################################################################################################################
//Programmspeicher beschreiben//написать програмную память
//############################################################################################################################################################

//Bild_01 (Globus)//земля
const byte bild_01[] PROGMEM=
{
